Canon EOS R5 C Body + 2 battery and charger (NO Memory Card)

NOTE: The Canon R5 features two memory card slots and is compatible with two different types of memory cards. It has one CFexpress Type-B card slot and one UHS-II SD card slot. CFexpress Type-A cards will not work.

Specifications in detail

Image Sensor

• Sensor
  3:2 Full Frame CMOS sensor (36 x 24mm)
• null
  RGB primary colour filter (Bayer array)
• Sensor Modes
  Full Frame (8K) / Super 35mm (Crop) / Super 16mm (Crop)
• Total Pixels
  Approx. 47.10 megapixels
• Effective Pixels
  Video Mode:
  Approx. 35.40 megapixels (8192 x 4320): When resolution is 8192 x 4320, 4096 x 2160, or 2048 x 1080
  Approx. 33.20 megapixels (7680 x 4320): When resolution is 7680 x 4320, 3840 x 2160, or 1920 x 1080Photo Mode:
  Approx. 45 megapixels (8192 x 5464)
• Effective Sensor Screen Size
  36.0 x 19.0 mm (40.7 mm on the diagonal): When resolution is 8192 x 4320, 4096 x 2160 or 2048 x 1080
  33.8 x 19.0 mm (38.8 mm on the diagonal): When resolution is 7680 x 4320, 3840 x 2160, or 1920 x 1080
• Dynamic Range
  Canon Log 3: 1600% / 14 stops (at ISO 800)
  Wide DR: 800% (at ISO 400)

Image Processor

• Type
  DIGIC X

Lens

• Lens Mount
  Canon RF mount
  Compatible lenses: All RF lenses and EF lenses
  (includes EF-S lenses/EF cinema lenses)
• Lens Magnification Factor
  Full Frame:
  Actual focal length x approx. 1.0Super 35mm (Crop):
  5952×3140, 4096×2160 or 2048×1080 resolution: Actual focal length x approx. 1.460
  3840×2160, 1920×1080 or 1270×720 resolution: Actual focal length x approx. 1.534Super 16mm (Crop):
  In 2976×1570 or 2048×1080 resolution: Actual focal length x approx. 2.920
  In 1920×1080 or 1270×720 resolution: Actual focal length x approx. 3.069
• Peripheral Illumination Correction
  Yes
• Chromatic Aberration Correction
  Yes
• Distortion Correction
  Yes, RF Mount lenses only
• Diffraction Correction
  Yes
• ND Filter
  No
• Focus Control
  Via lens, Browser Remote, Camera Connect or EOS Utility
• Iris Control (EF Mount Lenses)
  1/2-stop, 1/3-stop or FINE control
• Cooke/I Technology Support
  No
• Anamorphic Lens Support
  Yes, x2.0 / x1.8 / x1.3
• Image Stabilization System
  Yes, 5-axis Electronic IS. Coordinates with supported lenses featuring optical-IS for optimal performance

Recording

• Internal Recording Media
  1x CFexpress card (CFexpress 2.0 Type B)
  1x SD card (SD/SDHC/SDXC)
  (SD Card recording available at bitrates up to 650 Mbps)
• Recording Time¹
  Cinema RAW Light LT: 8192 x 4320 1070 Mbps: 63 Mins
  Cinema RAW Light ST: 8192 x 4320: 1650 Mbps 41 Mins
  Cinema RAW Light HQ: 5952 x 3140: 1770 Mbps 38 Mins
  XF-AVC / MXF: 4096×2160: 410 Mbps 156 Mins
  MP4 (HEVC): 4096×2160: 225 Mbps 285 Mins
  MP4 (H.264): 4096×2160: 150 Mbps 428 Mins
• Recording Formats
  Video Mode:
  Cinema RAW Light (CRM): 12-bit RAW
  XF-AVC (MXF):4:2:2 10-bit (ALL-I or Long GOP)
  HEVC (MP4): 4:2:2 10-bit / 4:2:0 10-bit
  H.264 (MP4): 4:2:0 8-bitPhoto Mode:
  RAW / C-RAW / Dual Pixel RAW² / HEIF³ / JPEG
• Relay Recording
  Yes
• Double Slot (Simultaneous) Recording
  Yes
• Simultaneous Recording in Multiple Formats
  Yes, in Dual Recording Mode
  Options Available: [CRL / XF-AVC / MP4] [All-I / Long GOP] [4:2:2 10-bit / 4:2:0 10-bit / 4:2:0 8-bit] [8K / 4K / 2K / FHD]
• System Frequency / Frame Rates
  59.94Hz mode (59.94P / 59.94i / 29.97P / 23.98P)
  50.00Hz mode (50.00P / 50.00i / 25.00P)
  24.00 Hz mode (24.00P)
• Cinema RAW Light Bit Rate/Bit Depth (PAL)
  12-bit Cinema RAW Light LT:⁴
  8192 x 4320 / 50P / 2140 Mbps: approx. 31 Mins
  8192 x 4320 / 25P / 1070 Mbps: approx. 63 Mins
  5952 x 3140 / 50P / 1140 Mbps: approx. 59 Mins
  5952 x 3140 / 25P / 556 Mbps: approx. 122 Mins
  2976 x 1570 / 50P / 287 Mbps: approx. 237 Mins
  2976 x 1570 / 25P / 144 Mbps: approx. 474 Mins12-bit Cinema RAW Light ST:
  8192 x 4320 / 25P / 1650 Mbps: approx. 41 Mins
  5952 x 3140 / 50P / 1750 Mbps: approx. 39 Mins
  5952 x 3140 / 25P / 871 Mbps: approx. 78 Mins
  2976 x 1570 / 50P / 441 Mbps: approx. 154 Mins
  2976 x 1570 / 25P / 221 Mbps: approx. 308 Mins12-bit Cinema RAW Light HQ:
  5952 x 3140 / 25P / 1770 Mbps: approx. 38 Mins
  2976 x 1570 / 50P / 896 Mbps: approx. 76 Mins
  2976 x 1570 / 25P / 448 Mbps: approx. 152 Mins
• XF-AVC Recording Bit Rate / Sampling (PAL)
  4:2:2 10-bit (Intra-frame):⁵
  4096×2160 or 3840×2160 / 50P / 810 Mbps: approx. 79 Mins
  4096×2160 or 3840×2160 / 25P / 410 Mbps: approx. 156 Mins
  2048×1080 or 1920×1080 / 50P or 50i / 310 Mbps: approx. 207 Mins
  2048×1080 or 1920×1080 / 25P / 160 Mbps: approx. 401 Mins4:2:2 10-bit (Long GOP):
  4096×2160 or 3840×2160 / 50P / 260 Mbps: approx. 246 Mins
  4096×2160 or 3840×2160 / 25P / 160 Mbps: approx. 401 Mins
  2048×1080 or 1920×1080 / 50P or 50i / 50 Mbps: approx. 1284 Mins
  2048×1080 or 1920×1080 / 25P / 50 Mbps: approx. 1284 Mins
• MP4 Recording Bit Rate / Sampling (PAL)
  HEVC 4:2:2 10-bit (Long GOP):⁶
  8192×4320 or 7680×4320 / 25P / 540 Mbps: approx. 118 Mins
  4096×2160 or 3840×2160 / 50P / 225 Mbps: approx. 285 Mins
  4096×2160 or 3840×2160 / 25P / 135 Mbps: approx. 475 Mins
  2048×1080 or 1920×1080 / 50P or 25P / 50 Mbps: approx. 1284 MinsHEVC 4:2:0 10-bit (Long GOP):
  8192×4320 or 7680×4320 / 25P / 400 Mbps: approx. 160 Mins
  4096×2160 or 3840×2160 / 50P / 170 Mbps: approx. 377 Mins
  4096×2160 or 3840×2160 / 25P / 100 Mbps: approx. 642 Mins
  2048×1080 or 1920×1080 / 50P or 25P / 35 Mbps: approx. 1834 MinsH.264 4:2:0 8-bit (Long GOP):
  4096×2160 or 3840×2160 / 50P or 25P / 150 Mbps: approx. 428 Mins
  2048×1080 or 1920×1080 / 50P or 25P / 35 Mbps: approx. 1834 Mins
• Proxy Recording Bit Rate / Sampling (PAL)
  XF-AVC 4:2:0 8-bit (Long GOP)
  2048 X 1080 or 1920 x 1080 / 50P / 35 Mbps
  2048 X 1080 or 1920 x 1080 / 25P / 24 MbpsH.264 MP4 4:2:0 8-bit (Long GOP)
  2048 X 1080 or 1920 x 1080 / 50P or 25P / 9 Mbps
• Slow/Fast Motion
  8K recording up to 30FPS (60FPS with external power)
  4K / FHD recording: up to 120FPS
  Audio recording and auto-focus options available.
• Interval Record
  Yes
• Frame Record
  Yes
• Pre Record (Cache Record)
  Yes, 3 seconds (XF-AVC or MP4 recording only)
• Scan Reverse
  Yes
• Photo Recording Size
  3:2 ratio:
  (L, RAW, C-RAW) 8192×5464, (M1) 5808×3872, (S1) 4176×2784, (S2) 2400×1600
  1.6x (crop):
  (L) 5088×3392, (S2) 2400×1600
  4:3 ratio:
  (L) 7280×5464, (M1) 5152×3872, (S1) 3712×2784, (S2) 2112×1600
  16:9 ratio:
  (L) 8192×4608, (M1) 5808×3264, (S1) 4176×2344, (S2) 2400×1344
  1:1 ratio:
  (L) 5456×5456, (M1) 3872×3872, (S1) 2784×2784, (S2) 1600×1600
