DJI Mic 2 Wireless Microphone Kit – (2 TX + 1 RX + Charging Case) + 2 Lav Mic

DJI Mic 2 Transmitter

Model
DMT02
Dimensions
46.06×30.96×21.83 mm (L×W×H)
Weight
28 g
Wireless Mode
GFSK 1 Mbps and 2 Mbps
Equivalent Isotropic Radiated Power (EIRP)
<20 dBm
Wireless Mode Operating Frequency
2.400-2.4835 GHz
Bluetooth Protocol
BR/EDR
Bluetooth Operating Frequency
2.400-2.4835 GHz
Bluetooth Transmitter Power (EIRP)
<20 dBm
Battery Type
Li-ion
Battery Capacity
360 mAh
Battery Energy
1.39 Wh
Battery Voltage
3.87 V
Charging Temperature
5° to 45° C (41° to 113° F)
Operating Temperature
-10° to 45° C (14° to 113° F)
Charging Time
70 mins
Operating Time
6 hours
Tested when both TXs are connected to the RX without recording backup clips internally, and the RX is connected to a camera via Camera Audio Cable (3.5mm TRS).
DJI Mic 2 Receiver

Model
DMR02
Dimensions
54.20×28.36×22.49 mm (L×W×H)
Weight
28 g
Wireless Mode
GFSK 1 Mbps and 2Mbps
Equivalent Isotropic Radiated Power (EIRP)
<20 dBm
Operating Frequency
2.400-2.4835 GHz
Battery Type
Li-ion
Battery Capacity
360 mAh
Battery Energy
1.39 Wh
Battery Voltage
3.87 V
Charging Temperature
5° to 45° C (41° to 113° F)
Operating Temperature
-10° to 45° C (14° to 113° F)
Charging Time
70 mins
Operating Time
6 hours
Tested when both TXs are connected to the RX without recording backup clips internally, and the RX is connected to a camera via Camera Audio Cable (3.5mm TRS).
DJI Mic 2 Charging Case

Model
DMC02
Dimensions
116×41.5×59.72 mm (L×W×H)
Weight
200 g
Battery Type
18650 Li-ion
Battery Capacity
3250 mAh
Battery Energy
11.7 Wh
Battery Voltage
3.6 V
Charging Specification
5 V, 1.5-3 A
Charging Temperature
5° to 40° C (41° to 104° F)
Operating Temperature
5° to 45° C (41° to 113° F)
Charging Time
2 hours and 40 mins
Charging Cycles for TX and RX
Approx. two cycles when charging two TXs and one RX at the same time
